Raymarine E90W - Using Radar to Track Targets and Avoid Collisions

Range -
1
/
4
nm
Range rings -
1
/
8
nm apart
Range -
3
/
4
nm
Range rings -
1
/
4
nm apart
Range - 1
1
/
2
nm
Range rings -
1
/
4
nm apart
D8407_1
e.g.
Enablinganddisablingradarrangerings
Intheradarapplication:
1.PresstheMENUbutton.
2.SelectRadarSetup.
3.UsetheRangeRingsmenuoptiontoswitchRadarRingsON
orOFF.
9.11Usingradartotracktargetsand
avoidcollisions
Thereareanumberofradarfunctionstohelpyoutracktargetsand
avoidcollisions,includingGuardZones,MARPA,andAIS.
Witharadarconnectedtoyourmultifunctiondisplay,youcan:
•Assesshowfarawayatargetisanditsbearing(VRMs/EBLs).
•Setanalarmtotriggerwhenatargetiswithinaspeciedzone
(GuardZones).
•Displaydetailedinformationontrackedtargets(MARPA).
•Displaytheidentityofothervesselsandifbroadcasted,their
voyageinformation(AIS).
•Displaytherangeandbearingofatarget.
Settinguparadarguardzone
Intheradarapplication:
1.PresstheTARGETTRACKINGsoftkey.
2.PresstheMONITORINZONESsoftkey.
3.PresstheZONE1orZONE2softkey(asappropriate)untilthe
ONorOFFoptionisselected.
4.PresstheSETUPZONE1orSETUPZONE2softkey,as
appropriate.
5.PresstheZONESHAPEsoftkeyuntiltheSECTORorCIRCLE
optionisselected,asrequired.
6.Usethesoftkeysandtherotarycontroltospecifytheguard
zone,asappropriate.
Adjustingguardzonesensitivity
1.PresstheMENUbutton.
2.SelectAlarmSetup.
140E-SeriesWidescreenUserreference
