In the PASSING MAKE CONTACT operator the
output follows the signal on the input.
However, if this is 1 (TRUE) for longer than the
set time, the output changes to 0 (FALSE).
When there is an input falling edge, the timer
is cleared.
Parameters
Time: The delay can be set to between .
Retriggerable: If selected the time is not reset when there is an input falling edge. The
output stays 1 (TRUE) for all the selected time. When there is a new input rising edge, the
timer restart again.
