Reer MOSAIC Master M1 User Manual

MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
48 8540780 • 30/03/2016 • Rev.26
English
MV1, MV2 (Figure 22)
Table 41 - Opening screen
if the unit is waiting
for the first
communication
from the MASTER
if no INPUT or
OUTPUT requested
by the
configuration
if INPUT or OUTPUT
requested by the
configuration
operation OK
operation OK
Shows the
NODE_SEL0/1
signal table
Encoder
connected and
operative
Proximity
connected and
operative
Axis in normal
speed range
Axis in stand
still
Axis in
overspeed
Table 42 - Dynamic screen
* NOT PRESENT ON MV0 MODULE
Figure 22 - MV1, MV2
