Reer MOSAIC Master M1 User Manual

MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
8540780 • 30/03/2016 • Rev.26 21
English
-
24VDC power supply
-
Input
Node selection
Input ( according to EN 61131-2)
Input
Input ( according to EN 61131-2)
-
0VDC power supply
-
Input
Feedback/Restart 1
Input (secondo EN 61131-2)
Input
Feedback/Restart 2
Input (secondo EN 61131-2)
Input
Feedback/Restart 3
Input (secondo EN 61131-2)
Input
Feedback/Restart 4
Input (secondo EN 61131-2)
Output
N.O. contact Channel 1
Output
Output
N.O. contact Channel 2
Output
Output
N.O. contact Channel 3
Output
Output
N.O. contact Channel 4
Output
Table 11
-
24VDC power supply
-
Input
Node selection
Input ( according
to EN 61131-2)
Input
Input ( according
to EN 61131-2)
-
0VDC power supply
-
Input
Feedback/Restart 1
Input (secondo EN 61131-2)
Input
Feedback/Restart 2
Input (secondo EN 61131-2)
Input
Feedback/Restart 3
Input (secondo EN 61131-2)
Input
Feedback/Restart 4
Input (secondo EN 61131-2)
Output
N.O. contact Channel 1
Output
Output
N.O. contact Channel 2
Output
Output
N.O. contact Channel 3
Output
Output
N.O. contact Channel 4
Output
Output
Programmable signal output 1
PNP active high
Output
Programmable signal output 2
PNP active high
Output
Programmable signal output 3
PNP active high
Output
Programmable signal output 4
PNP active high
Output
Programmable signal output 5
PNP active high
Output
Programmable signal output 6
PNP active high
Output
Programmable signal output 7
PNP active high
Output
Programmable signal output 8
PNP active high
Table 12
