V 01/2016
RT100 Control System Design and Function 5
Design and Function
Range of Application
The RT100 Control System has been developed for the control and op-
eration of Regloplas temperature control units and in addition, facilitates
connection to a superordinate control system of a production plant.
Software Version
NOTE
The following description of the RT100 Control System and its parameterisation
is valid beginning with software version 1119.
RT100 Control System - Hardware
Construction
The microprocessor-controlled RT100 Control System from Regloplas
consists of a front panel (operation and display section) and a base mod-
ule (power section).
CAUTION
No external, third-party devices may be connected to the 24 VDC supply and the
AC supply of the base module!
Operation Concept
The RT100 Control System is equipped with an RCD control knob. It can
be used for navigation in the user interface through simple rotating and
pressing.
Pressing once selects a value and turning the knob is used for configura-
tion. Pressing again accepts the value.
