V 01/2016
20 Parameterisation RT100 Control System
Parameters Remarks
Next service Display of the remaining operating hours up to the next maintenance
Interface Display of the interface (with code)
Address Display of the device address in case of operation via interface
Date Display of the current date
Time Display of the current time
Num. level 1 low Display of the number of level undershoots
Control cabinet temp. Current temperature in the control cabinet (in °C/°F)
Software Version Display of the implemented software version (front panel/base module)
Corr. set-point Set-point value for auxiliary controller of the cascade control
Flow deviation Deviation of the flow rate in l/min or GPM
Select language
(Password level - Technician password)
One of the languages currently available is selected in this menu (second
line, German is in first line, English in second line).
The available languages are English, German, French, Italian, Spanish,
Dutch, Czech, Chinese, Russian, Slovenian, Polish, Danish, Hungarian,
Croatian, Romanian, Portuguese, Swedish and Japanese.
User settings
(Password level - Technician password)
Display
Parameters Remarks
Contrast Contrast of the display (in %)
Temperature display Temperature display (in °C / 0.1 °C or °F)
Flow display Flow display (in lpm or usGPM or ukGPM)
Zone display Zone display (Manually or Auto)
Zone Input of zone display if configuration is set on Manually
Clock
Parameter Remarks
Time format Selection of the time format (12/24-hour format)
Synchronize Synchronisation of date and time
Switch clock
Parameter Remarks
Clock programming
(Software option)
Programming the clock (10 steps)
There are 10 steps (connections) available for programming the clock. A day-of-
the-week, a group of days of the week, a time and the type of time (on/off time)
must be programmed for every step. 2 steps are required so that the device is
switched on once and off thereafter. The steps that are not required are set to inac-
tive. The active (On/Off) and inactive steps are visible in the second sub-level
