V 01/2016
46 Plug Nomenclature RT100 Control System
RT100 Digital Option
The digital functions of the RT100 Digital Option are mirrored identically
on the RT100 Analog Option.
Digital Functions
Plug Designation
X80:1 External heating
X80:2 External cooling
X80:3 External heating/cooling active
X80:4 External On/Off
X80:5 External toggling SP1-SP2
X80:6 Differential pressure, filter
X80:7 External Start program
X80:8 External Stop program
X80:9 GND X80: 1-8
Relay Functions
Plug Designation
X81:1 Relay K2 NO
X81:2 Relay K2 COM
X81:3 Relay K2 NC
X81:4 Relay K3 NO
X81:5 Relay K3 COM
X81:6 Relay K3 NC
X81:7 Relay K4 NO
X81:8 Relay K4 COM
X81:9 Relay K4 NC
RT100 Analog Option
Digital Functions
Plug Designation
X100:1 External heating
X100:2 External cooling
X100:3 External heating/cooling active
X100:4 External On/Off
X100:5 External toggling SP1-SP2
X100:6 Differential pressure, filter
X100:7 External Start program
X100:8 External Stop program
X100:9 GND X100: 1-8
