REGLOPLAS RT100 - Parameterisation

V 01/2016
RT100 Control System Parameterisation  19
Parameterisation
General
The parameterisation of the RT100 Control System is carried out with the
Parameter button in the menu Parameters. The corresponding parame-
ter is selected and set by turning/pressing the RCD control knob.
The parameters are described in the following chapters.
CAUTION
The RT100 Control System has a safety concept with different password levels.
Parameters with the password level "Service Engineer" may only be adjusted
by personnel trained by Regloplas. Regloplas AG is not liable for damage that
results from incorrect parameterisation!
Show actual values
(Password level - User password)
The respective current actual values are displayed in this menu:
Parameters Remarks
Outlet temp.
Temperature of the heat transfer medium in the outlet - sensor Sn1 (in
°C/°F)
External temp. Temperature of the consumer in - sensor Sn1 (in °C/°F)
Inlet temp.
Temperature of the heat transfer medium in the inlet - sensor Sn3 (in
°C/°F)
Heat./cool. power
Specification of the momentary output in % of the rated output
(a negative value means cooling capacity in %)
Flow rate Flow rate of the heat transfer medium in l/min or GPM
Pump pressure Differential pressure across the pump
Pressure set-point Pressure set-point value of the heat transfer medium (bar)
System pressure Pressure of the heat transfer medium in the system (bar)
Outlet pressure Pressure of the heat transfer medium in the outlet (bar)
Pump current L1 Current drawn by the pump motor - Phase 1 (in A)
Pump current L2 Current drawn by the pump motor - Phase 2 (in A)
Pump current L3 Current drawn by the pump motor - Phase 3 (in A)
Operating hours Number of operating hours of the temperature control unit
