V 01/2016
RT100 Control System Technical Data 17
Precision
RT100 Control System
Class accuracy / linearization
0.3 % of the display value, min. 0.5 °C
Pt100: 0,3 %
Thermocouples: 0,3 %
Deviation of the display
Pt100: 1 digit
Thermocouples: 2 digits
Operation
RT100 Control System
Operation
Operation using short-travel membrane key switch with pressure point in
the membrane keyboard and RCD control knob (Regloplas Control Dial).
Simple menu guidance in different languages. Set-point value and param-
eterisation protected through programmable codes
Dimensions
RT100 Control System
Front dimensions 130 x 140 mm
Base module 170 x 230 mm
