REGLOPLAS RT100 - Ramp Program (Software Option)

V 01/2016
RT100 Control System Parameterisation  21
Parameter Remarks
Step 1-10
On/Off/Program 1-5 (Ramp pro-
gram)/Inactive
Monday, Tuesday, Wednesday, Thurs-
day, Friday, Saturday, Sunday, Mo-Th,
Mo-Fr, Mo-Sa, Mo-Su
Time
Ramp program (Software option)
(Password level - Technician password)
Parameter Range Remarks
Status
Program
Display the status of the cur-
rent ramp program
Status
Loop
Step
Actual value
Set-point value
End set-point value
Remaining step time
Program control
Program Display ramp program
Status Display status
START Start ramp program
PAUSE Pause ramp program
STOP + RESET Stop/Reset Ramp program
Program admin-
istration
Program 1
No. of steps Program steps (2-20)
Start step Starting steps (1-20)
Start trigger
Start takes place manual-
ly/clock
Stop behaviour
Switching off/last set-point
value
No. of loops Program passes (1-99)
Steps
Step 1
Set-point (in °C/°F)
Ramp time (in hrs./min.)
Dwell time (in hrs./min.)
Start dwell time ("Directly" or
when "Set-point reached")
Step 2 (Functions like Step 1)
Step 3 (Functions like Step 1)
Step 4 (Functions like Step 1)
Step 5 (Functions like Step 1)
Program 2 (Functions like Program 1)
Program 3 (Functions like Program 1)
Program 4 (Functions like Program 1)
Program 5 (Functions like Program 1)
