RT100 Control System Technical Data 15
Technical Data
RT100 Control System
General Data
RT100 Control System
Temperature range -25 - 450 °C
Control response
Outlet control:
PID-controller, with 10 hard-coded PID parameter sets or with a PID set
that can be set manually. Separate parameter sets for heating and cooling
Consumer control:
PID-controller, with 10 hard-coded PID parameter sets or with a PID set
that can be set manually
Parameter input Input via keyboard and RCD control knob
Data memory
Memory module with at least 10 years data retention time
Timer with Lithium battery and about 10 years data retention time
Limit values
Adjustable maximum set-point value limit
Programmable minimum and maximum deviation from the set-point value
of the heat transfer medium temperature and consumer temperature
Monitoring equipment
Continuous self-monitoring of the regulation and control system
Probe breakage and sensor short-circuit (only in case of Pt100), probe
breakage
Limit values for temperature, pump current (all 3 phases), level, function
of the heating and pump circuit breakers and the flow rate (option)
Monitoring the plausibility of the data in the memory, the maintenance in-
terval, the flow monitor, the calibration values, the phase sequence of the
pump motor in compression or suction operation and of the external set-
point value signal (option)
Electrical Data
RT100 Control System
Input supply voltage Power supply (85-265 VAC)
Degree of protection Front panel with membrane keyboard (IP54)
Maintenance
Plug-in data memory, permanently connected to the temperature control
device, for fast and simple changing of the base module without loss of
data The user data are automatically read into the new base module
Integrated working-hour meter and maintenance interval display
