RT100 Control System RT100 Control System - Maintenance/repair 61
RT100 Control System - Mainte-
nance/repair
Replacing the front panel
Removal
CAUTION
The exact sequence of operations described below must be strictly followed.
Otherwise, parameterization errors are possible!
The address of the base module must be correct before the control system is
powered up for the first time. Otherwise, the base module boot loader will have
to be reloaded by the manufacturer!
Disconnect all plug-in connections
The front panel is fixed with 6 screws on the device door. Loosen
all the screws and remove the defective front panel
Send the defective front panel to Regloplas AG (Switzerland) in
ESD protective packaging, complete with a description of the
fault
Installation
Fasten the front panel with 6 screws on the device door
Reconnect all plug-in connectors
Loading the firmware
See the section "RT100 Control System - Loading the firmware".
