V 01/2016
12 Design and Function RT100 Control System
Loading the firmware/bootloader
CAUTION
The firmware must be loaded the first time that the device is switched on (main
switch), otherwise, the parameter settings will be incorrect!
Insert the USB flash drive containing the firmware into the USB
port on the front panel
Press and hold down front panel buttons F1 and F2 simultane-
ously
Switch on the RT100 control system
The RT100 control system will now load the bootloader
As soon as the bootloader has loaded, the message Update
successful will be displayed
Press the panel button F1
The RT100 control system will now load the new firmware
Attention - during the loading process, the device may not be
switched off under any circumstances!
As soon as the firmware has loaded, the message Update suc-
cessful will be displayed
The device can now be started with button F1 on the front panel
The USB flash drive can be removed now
RT100 Control System - Activating Options
The RT100 control system can be equipped with different hardware and
software options.
The software options must be activated with a file loaded by USB stick.
This operation requires the serial number of the control system, which is
displayed in the Options parameter and can be found on the base mod-
ule next to the barcode. The serial number consists of 6 letters (e.g.
AALASF).
In the Options parameter, select the Activate options menu
Now insert the USB stick with the options file (e.g. AALASF.opt -
The options file can be on the same USB stick as the firmware)
Software options
Universal interface
Switch clock
Ramp program
Cascade inlet (sensor Sn3)
Flow measuring F150
Flow measuring F351
Flow measuring F1000
