34  Parameterisation RT100 Control System
Parameter Range Remarks
Analog output 1
(analog option)
Analog output 1
Inactive, 4-20 mA, 0-20 mA, 10 V, TE Type J,
TE Type N, TE Type T, TE Type K
Layout
Outlet temperature, External temperature,
Inlet temperature, Set-point value 1, Set-point
value 2, Flow, Set-point, Pump regulation
Lower end of scale in corresponding dimension unit
Upper end of scale in corresponding dimension unit
Offset in corresponding dimension unit
Analog output 2
(analog option)
Analog output 2
Inactive, 4-20 mA, 0-20 mA, 10 V, TE Type J,
TE Type N, TE Type T, TE Type K
Layout
Outlet temperature, External temperature,
Inlet temperature, Set-point value 1, Set-point
value 2, Flow, Set-point
Lower end of scale in corresponding dimension unit
Upper end of scale in corresponding dimension unit
Offset in corresponding dimension unit
Relay
(Password level - Technician password)
The parameters of the relay functions are displayed in this menu:
Parameter Range Remarks
Relay K1
Function
Input "Opening/Closing/Single shot lead.
edge"
Relay
Control unit ON
Clock activated
Pump running
Level 1 reached
Level 2 reached
Heating 1 ON
Heating 2 ON
Cooling ON
Pressure increase
Pressure decrease
Service
Max heat./cool. time
Power ON
Alarm
Common alarm (see the param-
eter " Common alarm")
Heating 1
Heating 2
Minimum flow rate
Flow monitor
Level
Pump current
Deviation Set-point/Outlet HI
