V 01/2016
28 Parameterisation RT100 Control System
Parameter Range Remarks
Neutral zone Input neutral zone (in bar)
Min. system pressure Input min. system pressure (in bar)
Vapour suppression Input of steam suppression (in sec.)
Pump regulation (Software option)
(Password level - Service password)
Parameter Remarks
Control type Input of the control type (Pump pressure, Flow rate or Delta T - Outlet/Inlet)
Operating mode Input of operating mode (Manually or Auto)
Pump pressure, Flow
rate or Delta T set-point
Input of set-point (in bar, lpm or °C)
Max. set-point Input of set-point (in bar, lpm or °C)
Min. set-point Input of set-point (in bar, lpm or °C)
Neutral zone Input of neutral zone (in bar, lpm or °C)
Kp Input of gain Kp
Reset time Input of reset time (in sec.)
Derivative time Input of derivative time (in sec.)
Max. output Setting the output (in Hz)
Min. output Setting the output (in Hz)
Hand-value Input of hand-value (in Hz)
Unit configuration
(Password level - Service password)
Parameter Remarks
Device type Selection of heat transfer medium (Water/Oil)
Max. device temp.
Input of the maximum temperature of the temperature control unit (in °C/°F, normal-
ly 5-10 °C above the max. set-point value)
Max. set-point
Input of the maximum set-point value of the heat transfer medium temperature in
°C/°F)
Behaviour after power
failure
Input behaviour after power failure ("Remains switched off", "Remains switched off -
without error" or "Last status")
Closing temperature Input of closing temperature (in °C/°F)
Pressure release
Pressure release type
Input pressure release type ("With pump",
"With Y8/Y8.1" or "Without")
Pressure release time Input pressure release time (in sec.)
Switch off
Behaviour Input "Cool first" or "Immediately off"
Run-on temperature Input run-on temperature when switching off
Run-on time Input run-on time of pump after switching off
Cooling capacity Input of cooling capacity for cooling process
Emptying (Software op-
tion)
Evacuation type
Input evacuation type ("Inactive", "With
pump" or "With pressure")
with pressure with Y8/with Y18
