V 01/2016
RT100 Control System Parameterisation 29
Parameter Remarks
Venting time Venting time duration (in sec.)
Evacuation time Evacuation time duration (in sec.)
Leak stop Allow leak stop Input allow leak stop (yes/no)
Pump
Nominal current, pump Input nominal current pump (in A)
Monitor phase sequence Input monitor phase sequence (yes/no)
Run-down time of pump Input run-down time of pump (in sec.)
Automatic reversal of direction of
rotation >9A
Input automatic reversal of direction of rota-
tion >9A (yes/no)
Boost pump
Monitoring Input active/inactive
Maximum running time Input in (in sec.)
Restart lockout Input in (in sec.)
Active from set pressure Input in (bar)
Heating
Output Heating
Input 'heating output' ("SSR AC", "SSR DC",
"SSR DC aux. cont." or "Contactor")
Heating 2 Input heating 2 (active/inactive)
Cooling
Cooling principle
Input cooling type ("Direct", "Indirect" or "Indi-
rect/direct")
Temperature switchpoint indi-
rect/direct
Input of switching point (in °C/°F)
Cooling medium conveying
Input of cooling medium conveying ("With
SK-pump", "Without SK-pump" or "With 3-
way valve")
Antiblocking SK-pump
Active/Inactive if cooling medium conveying
is set "With SK-pump" (Activation of SK-
pump every 30 min. for 100 milliseconds)
Cooling valve reset time Input of reset time, cooling valve (in sec.)
Level
Refilling after
Input refilling after ("Power on" or "Control
on")
Run-on time, pump Input run-on time of pump (in sec.)
Refilling time window Input of refilling time window (in sec.)
Level counter Input active/inactive
Number of level undershoots Input possible number of level undershoots
Alarm suppression time Input of alarm suppression time (in minutes)
Number of fluid reservoir Number of heat transfer medium container
Monitoring Y2 Input Active/Inactive
Max. turn on time Y2 Input turn on time (in sec.)
Response delay Input (in sec.)
Min. refill time Input (in sec.)
Flushing
Flushing
Input flushing time ("Off", "With Y19" or "With
Y2/Y8")
Settings
Start flushing (Active/Inactive)
Start flushing time (in sec.)
Max. flushing tem-
perature
(in °C)
Interval flushing (Active/Inactive)
Interval time (in min.)
Interval flushing
time
(in sec.)
