V 01/2016
RT100 Control System Parameterisation 23
Next Service
Parameter Remarks
Operating hours Display of the operating hours
Next service Setting the period up to the next maintenance (0 h = disabled)
Pump regulation
Parameter Remarks
Pump pressure, Flow or
Delta T set-point
Set-point setting (in bar, lpm or °C)
Operating mode Operating mode setting (Manually or Auto)
Hand-value Setting in Hz
USB Logging (Service Interface)
Parameter Remarks
Service Interface (USB
Logging)
Data-Logging on USB-Stick "Active", "Inactive"
The USB Data logger is used for process-logging during production if no
superordinate control is present.
If the USB logging is set on "active" and an USB flash drive is plugged in,
every 10 seconds a record will be made. Per day (24 h) a file with the
date in the file name and with the suffix "lo1" will be created (e.g.
"20120825.lo1"). The records are provided with time and date.
In each case Set-point, Outlet temperature, External temperature, Inlet
temperature, Heating-/Cooling performance, Flow rate, Pump pressure,
System pressure and Pressure set-point will be stored. The csv file can
for example be imported into Excel. There is also a special import filter
for the Famos Reader software for quick overviews of data. Please use a
Regloplas USB flash drive for USB logging (part no. 176-100026).
Monitoring
(Password level - Technician password)
Temperature deviation
Parameter Remarks
Set-point value/outlet LO Monitoring of this parameter can be switched on/off (value adjustable in °C/°F)
Set-point value/outlet HI Monitoring of this parameter can be switched on/off (value adjustable in °C/°F)
Set-point value/external
LO
Monitoring of this parameter can be switched on/off (value adjustable in °C/°F)
Set-point value/external
HI
Monitoring of this parameter can be switched on/off (value adjustable in °C/°F)
Set-point value/Inlet LO Monitoring of this parameter can be switched on/off (value adjustable in °C/°F)
Set-point value/Inlet HI Monitoring of this parameter can be switched on/off (value adjustable in °C/°F)
Outlet/Inlet LO Monitoring of this parameter can be switched on/off (value adjustable in °C/°F)
Outlet/Inlet HI Monitoring of this parameter can be switched on/off (value adjustable in °C/°F)
