RT100 Control System Hardware 49
Hardware
RT100 Front Panel - Layout
RT100 Front Panel Print - Layout
CAUTION
Electronic parts can be damaged by electrostatic charges. For this reason,
proper grounding must be ensured during installation!
Fasten an antistatic wristband to your wrist before installing electronic compo-
nents!
