62 RT100 Control System - Maintenance/repair RT100 Control System
Replacing the base module
Removal
CAUTION
The exact sequence of operations described below must be strictly followed.
Otherwise, parameterization errors are possible!
The address of the base module must be correct before the control system is
powered up for the first time. Otherwise, the base module boot loader will have
to be reloaded by the manufacturer!
Disconnect all plug-in connections
Carefully unplug the memory card
The base card is fixed inside the device with 6 screws. Loosen all
the screws in alternation so that the plastic spacer bolts do not
fall out
Send the defective base module card to Regloplas AG (Switzer-
land) in ESD protective packaging, complete with a description of
the fault
Installation
Fasten the base card inside the device with 6 screws. Tighten
the screws in alternation to avoid twisting the base card
Reconnect all plug-in connectors
Carefully reinsert the memory card
Hardware checklist
Is the CAN connecting cable correctly plugged in?
Are the CAN terminating resistors set to the correct ON/OFF po-
sition?
Are the addresses of the base module (main units) correctly set?
(zone 1 = address 0, zone 2 = address 1 - very important for dual
devices with a single display)
Is the motor fuse F10 (10 A aM/Class CC) fitted?
Is the relay plug K1 connected?
Loading the firmware
See the section "RT100 Control System - Loading the firmware".
Activating options
See the section "RT100 Control System - Activating options".
