V 01/2016
RT100 Control System Parameterisation 31
Parameter Range Remarks
Code 4
The unit can be switched on and off as fol-
lows (closing of the external contact - unit
switches on / opening of the external contact
- unit switches off, the ON/OFF buttons, leak
stop and discharge as well as start/stop by
serial interface are inactive)
Code 5
The unit will be switched off immediately by
closing of the external contact - Warning De-
vice external switched off immediately will
be shown.
The unit can not be switched on until the con-
tact will be opened. There will be no cooling
or pressure relief, so the device may still be
very hot and under pressure!
Code 6
The unit will be switched off immediately by
closing of the external contact - Warning De-
vice external switched off immediately will
be shown.
The unit can not be switched on until the con-
tact will be closed. There will be no cooling or
pressure relief, so the device may still be very
hot and under pressure!
For code 2 and 3, the following applies:
Switching on and off with the button ON/OFF is possible at any time
Differential pressure filter
(digital or analog option)
Input "Opening/Closing"
Flow meter type F1000 (Software option, max.
300 lpm)
Parameters Remarks
Flow meter Active/inactive
Flow meter type F1000
Pump type Display of the pump type
Settings (see the following chapter "Settings")
Settings
Parameters Remarks
Pump tolerance
Deviation in % of the expected max. pump pressure. If this value is not reached,
an error message will be shown ("Pump power too low")
Pump calibration value Correction value of the pump calibration (can also be input manually)
Pump pressure
ON - Differential pressure outlet/system
OFF - only outlet pressure
Filtering time constant Averaging time of the flow
Automatic calibration Switching automatic pump calibration on or off
Manual calibration Start manual calibration
Pump pressure Display of the pump pressure during calibration
Manual calibration
Manual calibration starts when, in the menu, the parameter Manual cali-
bration is set to ON. The user is thereupon prompted to close the ball
valve in the outlet (flow = 0 l/min). When the ball valve is closed, the pa-
