REGLOPLAS RT100 - Data Interfaces; Basic Concept; Protocols

V 01/2016
RT100 Control System Data Interfaces  41
Data Interfaces
Basic Concept
The operation with data interfaces makes possible an external, superor-
dinate control system of the temperature control unit. The choice of the
protocol and the address of the data interface is described in the Param-
eterisation chapter.
Protocols
Designation Baud rate Interface Address
Inactive
1
Aarburg 4800 Bd 20 mA-CL
2
Engel CL 4800 Bd 20 mA-CL
5
Stork 1200 Bd 20 mA-CL
6
Ferromatik Milacron 4800 Bd 20 mA-CL
7
Klöckner Desma 4800 Bd 20 mA-CL
8
Demag Ergotech 4800 Bd 20 mA-CL
9
Krauss Maffei 4800 Bd 20 mA-CL
10
Dr. Boy 4800 Bd RS 232
15
Sächsische Kunststofftechnik 4800 Bd RS 485
16
CAN Demag Ergocontrol 615 kBd A13-17
18
Engel RS232 4800 Bd RS 232
19
SPI 19.2 kBd RS 485 A32-255
20
SPI 9600 Bd RS 485 A32-255
21
SPI 4800 Bd RS 485 A32-255
22
SPI 2400 Bd RS 485 A32-255
23
SPI 1200 Bd RS 485 A32-255
24
Bühler Dataspeed 4800 Bd RS 485
25
Frech Datacontrol 9600 Bd A11-18
26
Frech Datacontrol 4800 Bd A11-18
27
Frech Datacontrol 2400 Bd A11-18
28
Frech Datacontrol 1200 Bd A11-18
29
CAN Demag Ergocontrol 500 kBd A13-17
30
CAN Demag Ergocontrol 250 kBd A13-17
