6  Design and Function RT100 Control System
Operating Control and Display Elements
RT100 Control System - front panel
Buttons
Setting the set-point value
Scrolling through pages
Setting the additional display Setting the parameters
Selection of the device functions (toggling
SP1/SP2, drainage by suction, leak-stop)
Alarm reset and alarm history
Button ON/OFF
Status LEDs
Normal operation
Warning
Alarm
Device Functions
Set-point value toggling SP1/SP2
Draining (suction or blowing out)
Leak-stop operation
Status display
Display of set-point value
(SP1/SP2), interface (UI)
or external control (Ext.)
RCD control knob
(Regloplas Control Dial)
Additional
display
Symbol area
Display of Zone and tempera-
ture sensor Sn1/Sn2/Sn3
Interface
address
Status LEDs
Selection of the
device functions
Display of actual
value
