V 01/2016
RT100 Control System Parameterisation 25
Min. system pressure
Parameter Remarks
Min. system pressure Input - min. system pressure (Active/Inactive)
Min. system pressure Input - min. system pressure (in bar)
Alarm suppression Setting of duration of the alarm suppression (in sec.)
Interfaces
(Password level - User password)
The universal interface is available as a software option.
Address
Parameter Remarks
Address Address input (0-999)
Protocol Display of the current protocol with baud rate
Change protocol Selection/setting of the available protocols (see chapter Data Interfaces)
Temperature control
(Password level - Technician password)
Temperature Regulation
Parameter Remarks
Contr. type Ext./outlet casc., Inlet/Outlet casc. or Outlet type
Outlet control par. Control type with sensor in the outlet
Cascade external/outlet Control type with sensor in the consumer and in the outlet
Cascade inlet/outlet Control type with sensor in the inlet and in the outlet
Control parameters outlet
Parameter Range Remarks
Control parameter set Fixed/manual Selection of control parameter set
Control parameter
outlet defined
Parameter set Heating Selection of control parameter set Heating (1-10)
Parameter set Cooling Selection of control parameter set Cooling (1-10)
Control parameter
outlet manual
P Heating Setting control parameter P Heating (in °C/°F)
I Heating Setting control parameter I Heating (in sec.)
D Heating Setting control parameter D Heating (in sec.)
Capacity limitation
Heating
Capacity limitation Heating (0-100%)
P Cooling Setting control parameter P Cooling (in °C/°F)
I Cooling Setting control parameter I Cooling (in sec.)
D Cooling Setting control parameter D Cooling (in sec.)
Power limit cooling Capacity limitation Cooling (0-100%)
Neutral zone cooling
Setting of neutral zone cooling (0-10% of set-
point value)
