REGLOPLAS RT100 - Digital Option - Layout

V 01/2016
52  Hardware RT100 Control System
Digital Option - Layout
The digital functions of the RT100 Digital Option are mirrored identically
on the RT100 Analog Option.
Digital Option - Layout
CAUTION
If both a digital option and an analog option are installed, the digital functions
of the digital option must be used!
The digital functions of the analog option are not activated in this case!
Digital function
Relay function
