V 01/2016
RT100 Control System Parameterisation 35
Parameter Range Remarks
Deviation Set-point/Outlet LO
Deviation Set-point/External HI
Deviation Set-point/External LO
Deviation Set-point/Inlet HI
Deviation Set-point/Inlet LO
Deviation Outlet/Inlet HI
Deviation Outlet/Inlet LO
Deviation Flow rate
Temp. switch point (actual value in °C/°F)
Flow switch point (in lpm or GPM)
Band deviation (actual value in °C/°F)
Relay K2
(digital option)
Function Input "Normally open/Normally closed"
Relay (for functions, see relay K1)
Relay K3
(digital option)
Function Input "Normally open/Normally closed"
Relay (for functions, see relay K1)
Relay K4
(digital option)
Function Input "Normally open/Normally closed"
Relay (for functions, see relay K1)
Collective alarm
(Password level - Technician password)
The common alarm is configured in this menu. The common alarm can
be assigned to a relay or to a 24 VDC output.
Parameter Remarks
Alarm repeat time Input alarm repeat time (in sec.)
Heating 1 Input alarm heating 1 (On/Off)
Heating 2 Input alarm heating 2 (On/Off)
Min. flow rate Input alarm min. flow rate (On/Off)
Flow deviation Input alarm deviation of flow rate (On/Off)
Flow monitor Input alarm flow monitor (On/Off)
Level Input alarm level (On/Off)
Pump current Input alarm pump current (On/Off)
Temp. monitor cooling Input alarm cooling temperature monitor (On/Off)
Current monitor heating Input alarm Current monitor heating (On/Off)
SSR DC aux. contact Input SSR DC aux. contact (On/Off)
from SOF V1102:
In the case of the following alarms, the common alarm relay is always ac-
tivated:
Switch over heat carrier - reboot of the machine required
RTC Error or empty battery - Time and date settings lost
External set-point signal disconnected or not available
Direction of rotation cannot be changed
