REGLOPLAS RT100 - Fault Rectification; Error Messages, Alarms, and Warnings

V 01/2016
RT100 Control System Hardware  51
Analog Option - Layout
The digital functions of the RT100 Analog Option are mirrored identically
on the RT100 Digital Option.
Analog Option - Layout
CAUTION
If both a digital option and an analog option are installed, the digital functions
of the digital option must be used!
The digital functions of the analog option are not activated in this case!
Analog function
Digital function
