REGLOPLAS RT100 - Outputs

V 01/2016
RT100 Control System Parameterisation  33
Outputs
(Password level - Technician password)
The parameters of the signal outputs are displayed in this menu.
Parameter Range Remarks
24 VDC outputs
O1
Continuously inactive
Continuously active
Alarm
Common alarm (see the pa-
rameter "Common alarm")
Heating 1
Heating 2
Minimum flow rate
Flow monitor
Level
Pump current
Deviation Set-point value/Outlet
HI
Deviation Set-point value/Outlet
LO
Deviation Set-point/External HI
Deviation Set-point/External LO
Deviation Set-point/Inlet HI
Deviation Set-point/Inlet LO
Deviation Outlet/Inlet HI
Deviation Outlet/Inlet LO
Deviation Flow rate
Temp. switching point (in °C/°F)
Flow switching point (in lpm or GPM)
Band deviation (in °C/°F)
Control on
Clock active
Pump is running
Level 1 reached
Level 2 reached
Heating 1 on
Heating 2 on
Cooling on
Pressure increase
Pressure decrease
Maintenance
Pump regulation Start/Stop
O2
Data input output O2 (for functions, see out-
put O1)
Pump regulation Right/Left
O3
Data input: output O3 (for functions, see out-
put O1)
