V 01/2016
RT100 Control System Plug Nomenclature 43
Plug Nomenclature
RT100 Front panel
Plug Designation
X2 Options
X3 Base module
X4 Interfaces Universal RP or 20 mA CL
X5 USB Host
X6 USB Device
RT100 Base Module
Plug Designation
X1 Display and operations module (front panel)
X2 Base module
X3 Options
X4 Options
X5 Options
X6 Power supply
X7 EEprom (Memory)
X10:1 Flow monitor F3/B42
X10:2 Flow monitor F3/B42
X11:1 Level switch S3
X11:2 Level switch S3
X12:1 Level switch S1
X12:2 Level switch S1
X13:1 Digi In (Feedback frequency converter)
X13:2 Digi In (Feedback frequency converter)
X14:1 Digi In (Monitoring SK pump)
X14:2 Digi In (Monitoring SK pump)
X15:1 Sensor, internal (Pt100) B1
X15:2 Sensor, internal (Pt100) B1
X16:1 Sensor, external (Pt100 / TC+) B3
