V 01/2016
RT100 Control System Plug Nomenclature 47
Analog Functions
Plug Designation
X101:1 Analog input set-point value
X101:2 + 15 VDC
X101:3 Analog output 1 V
X101:4 Analog output 1 mA
X101:5 Analog output 1 TC
X101:6 Analog output 2 V
X101:7 Analog output 2 mA
X101:8 Analog output 2 TC
X101:9 GND outputs X101: 1, 3-8
RT100 Option Reversal of Direction of Rotation >9A
The RT100 option for reversal of the direction of rotation >9A is intended
for motor currents >9 A.
Plug Designation
X120:1 Pump motor T1
X120:2 Pump motor T2
X120:3 Pump motor T3
X120:4 Pump motor PE
X121:1 Mains supply L1
X121:2 Mains supply L2
X121:3 Mains supply L3
X121:4 Mains supply PE
RT100 Option Current Monitoring Heating
Plug Designation
X150:1 Current converter 1
X150:2 Current converter 1
X150:3 Current converter 2
X150:4 Current converter 2
