REI OSCOR Blue User Manual

SET-UP & BASIC OPERATION
6
12. Hard Reset – recessed switch for initiating a hard reset to the unit. This button should only be
used if the unit has locked up or is not functioning normally due to an unforeseen programming
condition.
13. USB-A connector – allows connection of USB flash memory for saving data. A USB keyboard or
mouse may also be connected to the unit to facilitate entry for the various fields.
14. Compact Flash slot – allows connection of compact flash card for saving data.
15. USB-B connector – Not currently utilized. Available for future software functionality.
16. Ethernet connector – Used to access the OSCOR unit remotely using VNC (Virtual Network
Computing) 3
rd
party software.
17. Whip Antenna Connector – for connecting the whip antenna accessory to improve low
frequency reception
