Reliable Controls SMART-Space Controller User Manual

95
 2012-2015 Reliable Controls Corporation
AMBIENT LIMITS
USER GUIDE
SPECIFICATIONS
SMART-SPACE CONTROLLER
™
AMBIENT LIMITS
PHYSICAL
ONBOARD TEMPERATURE SENSOR
INPUTS
Operating Temp 0 °C to 40 °C (32 °F to 104 °F)
Shipping Temp -40 °C to 60 °C (-40 °F to 140 °F)
Humidity 10% to 90% non-condensing
Dimensions 12.0 cm H x 7.0 cm W x 3.2 cm D
4
3
/
4
" H x 2
3
/
4
"
W x 1
1
/
4
" D
Weight 0.12 kg (0.254 lb)
Range 0 °C to 40 °C (32 °F to 104 °F)
Resolution 0.1 °C (0.18 °F)
Accuracy ± 1 °C (1.8 °F) over range
Quantity SSC has two universal inputs, SSCP and SSCE have
three universal inputs
Typ e Sel ecti on Jumper configurable
A/D Convertor 12-bit
Digital Input Dry contact
Impedance 1 M Ω on 0–10 VDC range
Pulse Counting Up to 40 Hz maximum
Overload Protection 24 VAC over-voltage protection
