BACNET NETWORK CONNECTION
A PC running RC-Studio or RC-Toolkit can communicate to SMART-Space Controllers
over a BACnet network using any of the standard connection methods detailed in Figure
32.
FIGURE 32: BACNET NETWORK CONNECTION
PTP - EIA-232
Proxy
B/IP over LAN
PTP - EIA-232
MS/TP - EIA-485
Router
B/IP over WAN
Switch
MS/TP - EIA-485
