DISPLAY CONFIGURATION
82
2012-2015 Reliable Controls Corporation
DISPLAY CONFIGURATION WORKSHEET COLUMNS
Table 13 describes the columns of the Display Configuration worksheet.
Backlight
Timeout The number of seconds the backlight will stay
on after the last use of the SMART-Space
Controller adjustment buttons. A value of 0 in
the Time-out field causes the backlight to be
continuously on.
Always off Select this field to disable the backlight.
Disable Hand/Off/Auto
Feature
Select this field to disable the output Hand/
Off/Auto feature via the LCD screen. This
feature is normally enabled by default.
After making changes to the SMART-Space Controller Setup dialog box, click the OK
button, and click the Mode button at the bottom of the Display Configuration dialog box to
send the changes to the controller.
TABLE 13: COLUMNS OF THE DISPLAY CONFIGURATION WORKSHEET
Column Description
Display Name Six character display name that will be displayed on the LCD
screen along with the current value of the object when the user
scrolls to the point. If this column field is left empty, the row
number will be displayed.
Point The mnemonic (e.g., 1301AV1, 1301SCHED1, etc) or name of the
BACnet object to be displayed. Objects can be dragged and
dropped from other worksheets.
Value The current value of the object.
Type Toggles between Analog or State to match the type of the object.
Range Successive clicks in this field will scroll to the possible ranges
associated with the Type selected, as follows:
State No/Yes, Stop/Start, Close/Open, Close/Open/Idle,
Off/On, Low/High, Cool/Heat, Off/Low/High,
On/Off/Auto, Fan: Off/Low/Med/High,
Off/Auto/Manual, Unoccupied/Occupied,
Auto/Manual, Low/High/Auto, Cool/Heat/Auto,
Cool/Heat/Auto/Off, Off/Low/High/Auto
TABLE 12: SMART-SPACE CONTROLLER SETUP DIALOG BOX FIELDS
Frame Field Description
