SHARING OBJECTS
68
2012-2015 Reliable Controls Corporation
10 IF OCC-SCHED THEN START SSC-BO1 ELSE STOP SSC-BO2
20 SSC-AV1 = AH1-OAT
30 IF+ AH1-SF-S THEN WRITE SSC-BV2 = 1
40 IF- AH1-SF-S THEN WRITE SSC-BV2 = 0
SHARE FUNCTION
The SHARE function is used by any Reliable Controls device that supports the SHARE
function MACH-Pro/Web/Com/Sys, MACH-Pro1, MACH-Pro2, controllers to share internal
BACnet objects to SMART-Space Controllers located on any of the MS/TP networks
connected to the device’s own EIA-485 ports. A device cannot SHARE a point that does
not exist in its own database.
The syntax for the SHARE function is as follows:
10 var = SHARE( object , arg )
Where…
var is a variable or local variable in the controller where the SHARE function is utilized. The
value of var increments according to the number of times the object is shared to the
network.
object is the name or mnemonic of a valid BACnet object located in the device where the
SHARE function is utilized.
arg is an optional Change of Value (COV) increment, valid only for shared analog values.
The COV increment is the minimum change in the value of the object required before the
object will be re-broadcast to the network. If arg is omitted, an increment of 1.0 is used.
The COV increment is not required and not valid for binary points.
SHARE-NET FUNCTION
The SHARE-NET function is used by any Reliable Controls device (except a MACH-Air,
MACH-Zone, or SMART-Space Controller) to share internal BACnet objects to SMART-
Space Controllers located on any specific MS/TP BACnet network in an internetwork.
The syntax for the SHARE-NET function is as follows:
10 var = SHARE-NET( net , object , arg )
Where…
var is a variable in the controller where the SHARE-NET function is utilized. The value of
var increments according to the number of times the object is shared to the network.
