PHYSICAL LAYOUT
4
2012-2015 Reliable Controls Corporation
PHYSICAL LAYOUT
FIGURE 2: PHYSICAL LAYOUT
Backplate
LCD screen
Optional occupancy sensor
Three-button keypad
Two 1.6 mm (
1
/16") Allen screws
(secure sensor head to backplate)
Cooling vents
Sensor head
X-Port-2 converter access port
Optional Deg C/Deg F switch
