Reliable Controls SMART-Space Controller User Manual

2
 2012-2015 Reliable Controls Corporation
NEW FOR REVISION E
This manual describes the operation of hardware Revision E of the SMART-Space
Controller series. There are several significant advances in Revision E hardware as
compared to the previous Revision C. There was no Revision D. The most significant
changes are listed below.
Two Firmware Versions!!!
Due to the changes in microprocessor and memory with Revision E hardware, the
firmware required for Revision E and pre-Revision E SMART-Space Controllers are NOT
compatible. Revision C Firmware will be required for Revision C and earlier controllers.
Revision E firmware will be required for Revision E and newer controllers.
• An optional CO2 sensor was made available.
• A thicker back-plate was added to provide more venting and more room for
models with the -CO2 option.
• Earlier hardware revisions all used TRIACs for their two-position outputs. The
TRIACS have been replaced with latching relays with superior in-rush rating and
less heat generation. This change also allows the SMART-Space Controller to
switch DC loads and loads with current draw below 20 mA if required. The
actual output wiring connections have not changed.
• The EOL jumper has been replaced with a more convenient EOL switch.
• Revision E hardware includes a faster microprocessor, with more RAM and
Flash (refer to the specifications section at the end of this User Guide).
• The maximum Control-BASIC program size has been increased from 1000 bytes
to 2000 bytes.
• The BACnet schedule in the Revision E SSC database can handle four start/stop
pairs per weekday, and 8 special events.
