RC-TOOLKIT BACNET MSET TOOL
USER GUIDE
SOFTWARE CONFIGURATION
SMART-SPACE CONTROLLER
™
RC-TOOLKIT BACNET MSET TOOL
The SMART-Space Controller was designed so that one or more units can be connected
to a live MS/TP network and powered up without any initial configuration required, and
without affecting existing communication on the network. This is possible because of the
following unique features:
It is possible to set the Media Access Code (MAC) of each controller using the onboard
button pad (see the Installation section of this manual); however, the RC-Toolkit BACnet
MSet Tool is a more efficient method to simultaneously configure multiple SMART-Space
Controllers.
The BACnet MSet Tool is a software application found in RC-Toolkit update 2.40, or later.
The main function of the BACnet MSet Tool is to allow one or more configured or
unconfigured SSCs to be discovered, named, and addressed from a single location.
• Baud configuration is not required, because the controller senses the network
baud and configures itself to communicate at the same rate.
• Every SMART-Space Controller ships without a MAC address, allowing
unconfigured units to remain silent and undiscovered on an MS/TP network
when powered up.
