Reliable Controls SMART-Space Controller User Manual

23
 2012-2015 Reliable Controls Corporation
STANDALONE APPLICATIONS
USER GUIDE
COMMUNICATIONS
SMART-SPACE CONTROLLER
™
COMMUNICATIONS
STANDALONE APPLICATIONS
SMART-Space Controller models with the -C option, including real-time clock and 72-hour
capacitor back up, can be installed as a standalone device. In this application,
RC-Toolkit, and RC-Studio can be used in conjunction with an X-Port-2
™
to configure the
SSC. The X-Port-2 must be connected to the access port located at the bottom of the
SMART-Space Controller enclosure.
FIGURE 19: X-PORT-2 CONNECTION
USB-CNV converter
CC-C1-B RJ11
to nine pin adaptor
CC-C1-C cableCC-VC-C cable
