AVAILABLE DATABASE OBJECTS
USER GUIDE
PROGRAMMING
SMART-SPACE CONTROLLER
™
PROGRAMMING
AVAILABLE DATABASE OBJECTS
The SMART-Space Controller uses many of the standard worksheets used in other MACH-
System controllers. Please refer to the RC-Studio Software Manual
for descriptions of how
to program or interpret these standard worksheets.
The following are the database objects available in a SMART-Space Controller:
Database programming information specific to the SMART-Space Controller is described
later in this manual.
Database Object Amount Details Mneumonic
System Group 1 (each allowing up to 30 object
annotations)
DISP
Display Configuration 1 DISP
Binary or Analog
Inputs
3-6 (depending on the model) BI#, AI#
Binary or Analog
Outputs
2-4 (depending on the model) BO#, AO#
Binary, Analog, or
Multistate Variables
32 (with up to 8 schedule operations
per day and 8 special events)
BV#, AV#,
MV#
PID Loops 2 LOOP#
BACnet Schedule 1 SCHED#
Multipoint Trend Logs 2 (each with up to 100 samples of
up to 8 trended objects)
MTL#
Single-point Trend
Log for every binary
object created
1 (each with up to 50 samples) STL#
Ta b le s 2 (each with 15 data points) TBL#
Control-BASIC 4 2000 bytes each PROG#
