Reliable Controls SMART-Space Controller User Manual

DISPLAY CONFIGURATION
78
 2012-2015 Reliable Controls Corporation
DISPLAY CONFIGURATION
The SMART-Space Controller LCD screen is custom configurable to display/adjust up to
10 BACnet objects. Configuration of the LCD screen is accomplished using RC-Studio,
update 1.50 or newer.
5 For analog outputs:
Auto = control by operators and Control-BASIC commands at the default
priority of 10
OFF = overrides Control-BASIC, and commands the output to the lowest
value of its defined range (eg. for a 0-100% range, the output would
be commanded to 0%)
ON = overrides Controls-BASIC, and commands the output to the highest
value of its defined range (eg. for a 0-10 VDC range, the output
would be commanded to 10 VDC)
6 After completing the intended override operation, no further action is required.
The display will automatically terminate HOA mode and return to the home
screen 30 seconds after the last button is pushed.
7 To disable the Hand Off Auto feature see the DISPLAY CONFIGURATION
section of the manual.
