Reliable Controls SMART-Space Controller User Manual

MODELS
8
 2012-2015 Reliable Controls Corporation
OPTIONS
In addition to the inputs and outputs listed above, Table 1 lists the options that are
available in any combination for all models.
For available standard models please refer to the Reliable Controls Engineering Submittal
sheet of the SMART-Space Controller.
To assemble a complete model number, the option codes are appended to the base
model number in order of -C, -D, -H, -OC, -CO2, and /W. Table 2 details two model
examples.
OUTPUT TYPES AND RANGES
Output types are either universal or relay. Universal outputs produce 0–12 VDC, with
modulating or two-position ranges configured using RC-Studio
®
. Relay outputs provide
normally open dry contacts that can switch sustained AC or DC loads up to 0.5 Amps. Note
that for SSCP models, the relay outputs can only switch the power supplied to the
controller. For example, if the controller is supplied with AC power, than the relay outputs
provide switched 24 VAC.
TABLE 1: MODEL OPTIONS
Option Description
-C Real-time clock with 72-hour capacitor backup
-CO2 0-2000 ppm CO2 sensor
-D Degrees Celsius/Fahrenheit selector switch
-H Humidity sensor
-OC Occupancy sensor
/W Solid white enclosure (warm gray is standard)
TABLE 2: EXAMPLES OF MODEL NUMBERS
Example Description
SSCE-C-D-H-OC SMART-Space Controller Enhanced unit with real-time clock,
degrees Celsius/Fahrenheit selector switch, humidity sensor,
and occupancy sensor
SSCP-H-OC-CO2/W
SMART-Space Controller Packaged unit with humidity sensor,
occupancy sensor, and CO2 sensor in a solid white
enclosure.
