SAMPLE WIRING DIAGRAMS

 2012-2015 Reliable Controls Corporation

SAMPLE WIRING DOCUMENT

SAMPLE WIRING DIAGRAMS

The following wiring diagrams are provided as examples of how to wire each of the three

base SMART-Space Controller models, using typical HVAC applications. Actual wiring

requirements will vary with each installation.

The following examples are provided:

• Example 1: SSC controlling a heating only fan coil.

• Example 2: SSCP controlling a packaged heat pump.

• Example 3: SSCE controlling a heat/cool fan coil with fresh air damper.
