PHYSICAL DIMENSIONS
6
 2012-2015 Reliable Controls Corporation
FIGURE 4: PHYSICAL DIMENSIONS (BACKPLATE)
0.43 cm
(
3
/
16
")
4.0 cm
(1
9
/
16
")
7.1 cm
(2
13
/
16
")
12.1 cm
(4
3
/
4
")
0.9 cm
(
3
/
8
")
1.9 cm
(
3
/
4
")
8.3 cm
(3
1
/
4
")
3.6 cm
(1
7
/
16
")
