INSTALLATION PROCEDURE
USER GUIDE
INSTALLATION
SMART-SPACE CONTROLLER
™
FIGURE 12: SSC OUTPUT JUMPERS
The metal strips in the square output jumper must be vertically aligned. Installing the jumper
with the metal strips horizontally aligned will result in incorrect output operation.
