Renault F4R - Page 142

10A-136
ENGINE AND CYLINDER BLOCK ASSEMBLY
Engine/gearbox assembly: Removal - Refitting
F9Q
10A
a Unclip the engine wiring (13) from the front end pa-
nel.
a Remove the bolts (14) from the engine wiring chan-
nel.
a Remove the front end panel bolts (15) .
135511
135647
135645
135646
