11A-14
TOP AND FRONT OF ENGINE
Accessories belt: Removal - Refitting
F9Q
11A
REFITTING
I - REFITTING PREPARATION OPERATION
a
a Clean the V-grooves of the crankshaft accessories
pulley.
a parts always to be replaced: Accessories belt
(10,10,01,03),
parts always to be replaced: Accessories belt
tensioning roller (10,10,01,04).
II - REFITTING OPERATION FOR PART
CONCERNED
a Refit the new accessories belt tensioning roller.
a Torque tighten the accessories belt tensioning
roller bolt (50 N.m).
a Refit the accessories belt.
a Turn the crankshaft twice.
III - FINAL OPERATION
a Refit:
-the front right-hand wheel arch liner (see Front
wheel arch liner: Removal - Refitting) (55A, Ex-
terior protection),
-the front right-hand wheel (see Wheel: Removal -
Refitting) (35A, Exterior protection),
-the engine undertray.
WARNING
Only use brushes with plastic or non-corrosive
metal (brass) bristles.
