11A-118
TOP AND FRONT OF ENGINE
Camshaft: Removal - Refitting
K9K
11A
a Disconnect the oil vapour rebreathing pipe from the
air filter unit air outlet pipe at (1) .
a Separate the clip (2) of the oil vapour rebreathing
pipe on the oil vapour rebreathing valve.
a Disconnect the oil vapour rebreathing pipe from the
oil vapour rebreathing valve.
a Remove the nut (3) from the gearbox breather pipe
mounting.
a Move aside the gearbox breather pipe mounting.
a Remove:
- the bolts (4) of the oil vapour rebreathing valve
K9K, and 830
135880
135879
135845
112325
