11A-121
TOP AND FRONT OF ENGINE
Camshaft: Removal - Refitting
K9K
11A
a Unclip the fuel return rail from the rocker cover at
(14) .
a Disconnect the oil vapour rebreathing pipe from the
rocker cover.
a Remove:
- the rocker cover bolts (15) ,
- the rocker cover,
- the rocker cover seal.
a Remove:
- the rocker cover bolts (16) ,
- the rocker cover,
K9K, and 830
135860
K9K, and 832
K9K, and 832
135489
K9K, and 830
135876
