11A-122
TOP AND FRONT OF ENGINE
Camshaft: Removal - Refitting
K9K
11A
-the rocker cover seal.
a Remove the vacuum pump (see Vacuum pump:
Removal - Refitting) (37A, Mechanical component
controls).
a Increase the hole (17) of the (Mot. 1606) (18) using
an 8.5 mm drill bit.
a Undo the camshaft pulley hub bolts (19) .
a Fit the (Mot. 1606) on the cylinder head to lock the
camshaft pulley wheel.
a Tighten the camshaft pulley hub bolts (19) .
a Remove:
- the nut (20) from the camshaft pulley,
- the (Mot. 1606),
- the camshaft pulley.
118982
118983
