TOP AND FRONT OF ENGINE
Cylinder head: Removal - Refitting
K4M
11A
-the coolant temperature sensor connector,
-the hose to the heater matrix,
-the top hose to the water chamber.
a Using the (Mot. 1448) or (Mot. 1202-01) or (Mot.
1202-02) fit:
-the clip on the heater matrix hose,
-the top hose clip on the water chamber.
a Refit:
-the injector rail (see 17B, Petrol injection, Injec-
tor rail - Injectors: Removal - Refitting, page
17B-19) ,
-the camshafts (see 11A, Top and front of engine,
Camshaft: Removal - Refitting, page 11A-114) ,
-the rocker cover (see 11A, Top and front of engi-
ne, Rocker cover: Removal - Refitting, page
11A-88) ,
-the oil separator (see 11A, Top and front of engi-
ne, Oil decanter: Removal - Refitting, page 11A-
205) .
a Refit:
-the camshaft dephaser (see 11A, Top and front of
engine, Camshaft dephaser: Removal - Refit-
ting, page 11A-177) ,
-the camshaft dephaser solenoid valve (see 11A,
Top and front of engine, Camshaft dephaser
solenoid valve: Removal - Refitting, page 11A-
184) ,
-the camshaft position sensor (see 17B, Petrol in-
jection, Camshaft position sensor: Removal -
Refitting, page 17B-13) .
a Refit:
-the camshaft seals (see 11A, Top and front of en-
gine, Camshaft seal at timing end: Removal -
Refitting, page 11A-186) ,
-the lifting eye.
a Torque tighten the lifting eye bolts (10 N.m).
a Fit the engine wiring on the lifting eye.
a Refit the dipstick guide.
a Torque tighten the dipstick guide tube bolt (10
N.m).
a Clip the wiring onto the lifting eye.
a Refit:
- the spark plugs (see 17A, Ignition, Spark plugs:
Removal - Refitting, page 17A-5) ,
- the ignition coils (see 17A, Ignition, Coils Remo-
val - Refitting, page 17A-1) ,
- the inlet manifold (see 12A, Fuel mixture, Inlet
manifold: Removal - Refitting, page 12A-23) ,
- the timing belt (see 11A, Top and front of engine,
Timing belt: Removal - Refitting, page 11A-29) ,
- the exhaust manifold stay,
-a new ring between the exhaust manifold and the
catalytic converter,
- the exhaust bracket,
- the crankshaft accessories pulley (see 11A, Top
and front of engine, Crankshaft accessories
pulley: Removal - Refitting, page 11A-15) ,
- the right-hand suspended engine mounting (see
19D, Engine mounting, Right-hand suspended
engine mounting: Removal - Refitting, page
19D-18) ,
- the accessories belt (see 11A, Top and front of
engine, Accessories belt: Removal - Refitting,
page 11A-7) ,
- the lower engine tie-bar (see 19D, Engine moun-
ting, Lower engine tie-bar: Removal - Refitting,
page 19D-33) ,
-the front bumper (see Front bumper: Removal -
Refitting) (55A, Exterior protection),
- the engine undertray,
- the front section of the front wheel arch liners (see
Front wheel arch liner: Removal - Refitting)
(55A, Exterior protection),
- the front wheels (see Wheel: Removal - Refitting)
(35A, Wheels and tyres),
- the scoop under the scuttle panel grille (see Scoop
under scuttle panel grille: Removal - Refitting)
(56A, Exterior equipment),
K4M, and 858 or 866
K4M, and 848
